Oil mist filtration system

product details

Oil mist filtration syste

AF oil mist machine series are environmentally products. It can filter out oil mist, water mist and other pollutants completely generating by mechanical equipment in the working to make the workshop environment best

Product model		AF850	AF1200	AF1800
Maximum air volume（m3/h）		850	1200	1800
static pressure（Pa）		150	200	250
Electrical parameters	power	0.2kW	0.3kW	0.8kW
Electrical parameters	Voltage	220V 50Hz
Filter element（LWH）mm		480340300	480340400	480340500
Front buffer plate		Aluminum Alloy screen frame filters
Pre filter		6 layers of aluminum alloy wire mesh / sealed package / double side band net
Electrostatic part	Plate spacing	7mm	7mm	7mm
Electrostatic part	Filtration area	0.096m2	0.129m2	0.296m2
Ionization device （Ionization filament）	diameter（mm）	Φ0.25	Φ0.25	Φ0.25
Ionization device （Ionization filament）	length（mm）	1800	2400	6200
High voltage（KV）		12/6	12/6	12/6
Collection device		3.0m2	4.0m2	10m2
back filter		Aluminum Alloy screen frame filters / activated carbon filter
noise		65db（A）	65db（A）	65db（A）
caliber（mm）		Φ150	Φ200	Φ250
weight（kg）		35	45	130
sizeLWH（mm）		640400630	640500630	1500620660
Note: 1, according to the demand for optional configuration of activated carbon filter 2, the product is modular design, according to the needs of customers to a certain degree of customization

Filtering method

Electrostatic filter (applicable to oil mist and smoke purification filter)

Mechanical filter (suitable for water purification and filtration)
